How to make Solar Mobile Charger fast charger for mobile

 Friends, we will sit in this post that how to make Solar Mobile Charger fast charger for mobile, you can also make Solar Mobile Charger in low price, for this you do not need to spend much, just in a little money, you can do it at your home. You can make Ampere mobile charger, I will tell you the complete information in Hindi, due to which you can make Phone Charger from Solar.


To make Solar Mobile Charger, you have to read this post properly so that you can understand. If you understand properly only then you will be able to remove more ampere from the solar panel and only then you will make fast charger for mobile. In this post we will tell you complete information with solar mobile charger diagram.


How To Make Solar Mobile Charger Fast Charger For Mobile And Any

Soler Mobile Charger केसै बनाएं fast charger for mobile


It is easy to make Solar Mobile Charger at home, when it is rainy season, then the electricity goes out at our house, only then the charge ends in our mobile, torch, and electric items living at home, only then we Solar Mobile Charger will be useful for us. But many people make this mistake that they put it directly on the battery, due to which the solar panel may get damaged or the battery may get damaged.

In this post, we will tell you how to Charger all the things that happen from Solar with Solar Mobile Charger with complete details, so read our full post to make Solar Mobile Charger at home I will tell you everything in different parts like Solar I will tell you complete information about mobile charger diagram, solar mobile charger image and accessories used. If you have any battery then you can also make Car mobile charger and Bike mobile charger at your home.

How to make Solar Mobile Charger: Essential accessories for fast charger for mobile

You will need this stuff while making solar mobile charger, you can buy this stuff both online and offline, in which you can buy online from Amazon.in also offline you will get it for ₹ 20/30.

7805 Transistor : Solar mobile charger

This transistor will be used to make solar mobile charger, whose job is to convert 12/35 volt DC power to 5 volt and our mobile is charged with 5 volt and it gives 1 ampere output if you make a 2 ampere head. Then you have to series two transistors

7812 Transistor Solar mobile charger

This transistor will be used for solar mobile charger, when you use watt solar plate, then you have to convert this power to 12v, after that you have to give power to 7805 transistor so that you transistor is not fuse
  1. Soler panel 20,30,40 watt
  2. 7805 Transistor 1/2/3
  3. 7812 Transistor
  4. Capacitor ×2
  5. Doide High Ampere
  6. Mobile charger cable

Where you can use Solar Mobile Charger fast charger for mobile

You can use this solar charger in place of bike mobile charger, car mobile charger, solar mobile charger mobile charger cable phone charger and 12 volt dc mobile charger but there is some difference in it which you need to understand then this sir ji for all of you can use

It can charge 12 volt DC battery from Solar mobile charger circuit. For which you have to check the diagram and there you can charge 12 volt battery on Red wire and Black wire 7812 transistor

With the help of solar mobile charger circuit, you can draw regular volt, you can run every electric product running on 5 volt and 12 volt. किसी भी AC/DC पावर को Regular कैसे करें

Soler mobile Charger Circuit Diagram - Soler wire connection

Solar mobile charger Diagram

See Solar mobile charger diagram properly Red wire (+) and Black wire (-) so you have to give in plus plus and minus in capital also.

12Volt Output: For this you have to take output from 7812 transistor, you can take output from 25v 2200uf.

5 Volt Output: For this you have to take output from 7805 transistor, you can take output from 10v 100uf.

Friends, I hope that this post will be useful to you in making solar mobile charger and bike mobile charger, car mobile charger, solar mobile charger, mobile charger cable, phone charger and 12 volt dc mobile charger, so hope you will definitely share it. Will do, if there is any Q, then you can definitely comment, thank you.
